The Kubota KX040-4 runs a 350x54.5Kx86 rubber track — 350 mm (14") wide, 54.5 mm pitch, 86 links, K-series guide lug profile. That K matters more than any other character in the size: order a 350x54.5x86 with the wrong lug profile and it won't seat on your rollers. Here's the full picture — verification, cost, and the undercarriage parts that wear out alongside the rubber.
Kubota KX040-4 Track Size
| Track size | 350x54.5Kx86 |
| Width | 350 mm (14") |
| Pitch | 54.5 mm |
| Links | 86 |
| Lug profile | K (Kubota-specific) |
| Tread pattern | Directional |
| Track weight | ~456 lb each |
Verify on the machine: the size is molded into the rubber on the inside or outside face of your current track. If it reads 350x54.5x86 or 350x54.5Kx86, this is your track.
Shop Kubota KX040-4 rubber tracks (350x54.5Kx86) →
Kubota KX040-4 Specs
| Class | 4-ton mini excavator, conventional tail swing |
| Engine | 36 HP diesel |
| Operating weight | 9,460 lb |
| Bucket dig force | 10,200 lb |
| Dig depth | 12'10" |
| Aux hydraulic flow | 15.1 GPM |
| System pressure | 3,626 PSI |
A 4-ton machine with over 10,000 lb of dig force loads its tracks hard in the trench — the K-profile lug and 14" width are what keep it planted while the bucket does the work.
What replacement tracks cost
A heavy-duty TrackTECH 350x54.5Kx86 track for the KX040-4 runs $1,283.78 per track — continuously wound steel cord that prevents snapping under load, abrasion-resistant rubber that resists cuts and chunking in rocky terrain, directional tread optimized for trenching and digging traction. Tested to last 30% longer than standard aftermarket tracks, backed by our 24-month full replacement warranty. Free freight to the lower 48, same-day shipping before 12 PM CT. Replace in pairs — mismatched wear pulls a digging machine off line exactly when you need precision.
KX040-4 undercarriage parts (with Kubota part numbers)
While the machine is up on the blade, inspect the steel — new rubber on worn steel is money thrown away:
- Drive sprocket — #RD118-14433 ($190): hooked or sharpened teeth chew the drive lugs off a new track. At $190 it's cheap insurance for a $1,280 track.
- Front idler — #RD118-21300 ($539): check for flange wear and side play.
- Bottom roller — #RD118-21700 ($167): highest-wear item under the frame. Spin each one — seized or leaking means replace.
- Top roller — #RD411-22900 ($115): flat spots cause track slap on the return run.
Other Kubota minis — don't cross sizes
Browse all Kubota rubber tracks and undercarriage parts or jump to the KX040-4 collection.
When to replace KX040-4 tracks
- Lug depth under 50% — trenching traction drops first, especially in wet clay
- Exposed or rusting steel cord — structural failure is coming; replace before it strands the machine in a trench
- Cracking between lugs — normal aging past ~1,500–2,000 hours
- De-tracking that tensioning won't fix — stretched cords are permanent
FAQ
What size track does a Kubota KX040-4 use?
350x54.5Kx86 — 350 mm wide, 54.5 mm pitch, 86 links, K lug profile.
What does the K in 350x54.5Kx86 mean?
It's the Kubota-specific guide lug profile. A track with the same numbers but a different lug profile will not seat correctly on the KX040-4 undercarriage.
How much does a Kubota KX040-4 weigh?
About 9,460 lb operating weight — a 4-ton class machine with 12'10" dig depth.
How long do KX040-4 tracks last?
Typically 1,200–2,000 hours — dirt and turf extend life, rock and demolition shorten it.
Should I replace both tracks at once?
Yes. Mismatched wear affects tracking and accelerates wear on the new side.
